Features
| TYPE | LB 325 | LB 425 | LB 525 | LB 625 | |
| X travel | mm | 3.060 | 4.060 | 5.060 | 6.060 |
| Y travel | mm | 2.550 | |||
| Z travel | mm | 800 | |||
| Distance from spindle to table | mm | 200-1.000 | |||
| Distance between columns | mm | 2.700 | |||
| Table dimensions | mm | 3.000×2.400 | 4.000×2.400 | 5.000×2.400 | 6.000×2.400 |
| Table load capacity | mm | 12.000 | 15.000 | 18.000 | 20.000 |
| Spindle speed | rpm | 10-6.000 | |||
| Spindle motor | Kw | 22/26 | |||
| Spindle torque | Nm | 626.2/740.1 | |||
| Spindle taper | – | BT 50 | |||
| Rapid traverse X/Y/Z | m/min | 24/20/15 | 18/20/15 | 15/20/15 | 12/20/15 |
| MODELO | LB 325 | LB 425 | LB 525 | LB 625 | |
| Recorrido eje X | mm | 3.060 | 4.060 | 5.060 | 6.060 |
| Recorrido eje Y | mm | 2.550 | |||
| Recorrido eje Z | mm | 800 | |||
| Distancia husillo-mesa | mm | 200-1.000 | |||
| Distancia entre columnas | mm | 2.700 | |||
| Dimensiones mesa | mm | 3.000x2.400 | 4.000x2.400 | 5.000x2.400 | 6.000x2.400 |
| Capacidad de carga | mm | 12.000 | 15.000 | 18.000 | 20.000 |
| Velocidad husillo | rpm | 10-6.000 | |||
| Motor husillo | Kw | 22/26 | |||
| Par husillo | Nm | 626.2/740.1 | |||
| Cono | - | BT 50 | |||
| Avance rápido X/Y/Z | m/min | 24/20/15 | 18/20/15 | 15/20/15 | 12/20/15 |
