Max. motion on the drilling head along the arm: 2.000 mm
Drilling capacity in steel: 63 mm
Drilling capacity in grey cast iron: 90 mm
Max. vertical displacement arm: 1.865 mm
Floor Plates and Angle Plates
Below is our offer of used angle plate and floor plates. Do not hesitate to contact us for more information. If you can’t find the angle plate or floor plate you are looking for, call us at +34 976 571213 and we will find the angle plate or floor plate that you need.
CNC Vertical Lathe MORANDO KN-20 Ø 2.000mm
Max turning diameter 2.200mm
Chuck diameter 2.000mm
Max. turning height 1.200mm
Loading capacity 12Tn
Bridge Milling machine CORREA FP-50/50
Longitudinal Travel 5.000mm
Cross Travel 3.250mm
Vertical Travel 1.000mm
Boring Machine CNC Amco Sacem Racem 601
Axis X – Traverse Column 6.000 mm
Axis Y – Headstok vertical travel 3.000 mm
Axis Z – RAM Stroke 1.000 mm
Axis W – Spindle Stroke 1.000 mm
Floor type horizontal boring mill Tos Varnsdorf WRD 150Q
X – Column longitudinal travel 10.000 mm
Y – Headstock vertical travel 4.000 mm
Z – RAM stroke 1.000 mm
W – Spindle stroke 800 mm
Universal grinder DANOBAT 1200-RP
Distancia entre puntos 1.200mm
Ø máximo a rectificar 345mm
Dimensiones de la muela 500x80x127mm
CNC TRAVELLING COLUMN MILLING MACHINE HURON
Curso longitudinal X 6.570mm
Curso vertical Y 1.880mm
Curso del carnero Z 1.170mm
CNC Vertical Lathe PIETRO CARNAGHI AC 24 TM SIEMENS 840
Table diameter 1.800mm
Max turning diameter 2.450mm
Max. cutting height (with toolholder of 180 mm) 1.500mm
Travelling column milling machine CME FCM8000
Longitudinal travel X: 8.000mm
Vertical travel Z: 2.000mm
RAM travel Y: 1.500mm
CNC VERTICAL LATHE HONOR SEIKI VL 100 CM
Diámetro del plato 1.000 mm
Diámetro máximo de volteo 1.200 mm
Diámetro máximo de torneado 1.200 mm
Altura máxima de torneado 650 mm
BRAKE DISC GRINDER STAR MACHINES XDL
Max. Diameter over carriage 440mm
Carriage travel 120mm
Max. Distance between tool holders 50mm
HYDRAULIC STEADY REST SMW AUTOBLOK SLUB 5.1
Capacidad 90-350mm
Presión min/máx 8/80bar
Anchura de rodillos 29mm
CLAMPING BRACKETS Tos Varnsdorf UU 1620
X – Ancho 700mm
Y – Alto 1.620mm
Z – Fondo 725mm
Clamping brackets Tos Varnsdorf UU 2500
X – Ancho 1.000mm
Y – Alto 2.500mm
Z – Fondo 1.200mm
Floor plate Tos Varnsdorf UD4
Superficie 4.020×1.885mm
Altura 400mm
Rotary table Tos Varnsdorf S 80
Capacidad de carga 80.000Kgs
Dimensiones mesa, de 3500x3500mm a 4000x4500mm
Rotary table Tos Varnsdorf S 16
Capacidad de carga 16.000Kgs
Dimensiones mesa, de 1800×2240 a 2000x2500mm
Rotary table Tos Varnsdorf S 30
Capacidad de carga 30.000Kgs
Dimensiones mesa, de 2000x2000mm a 3000x3500mm
MOVABLE TABLE 1.800×545 mm
Mesa desplazable 1.800x545mm
GEAR SHAPING PFAUTER P1501
Module M16
Max. wheel diameter 1.200mm
Workpiece diameter 1.500mm
